Reverse Laminar Air Flow


Reverse Laminar Air Flow

Designed with precision, the Reverse Laminar Air Flow is ideal for Operator Protection, Product Protection and Environment Protection. Based on the smooth working profile and high-end performance of our Reverse Laminar Air Flow, we are ranked amidst notable Reverse Laminar Air Flow Manufacturers, Suppliers and Exporters from India. Furthermore, Reverse Laminar Air Flow can be customized to suit the precise requirements of the clients.

Specifications :
  • Maximum protection from airborne contaminants produced at the time of powder handling operations such as charging, sampling, and dispensing
  • Powder coated Mild Steel, SS 304 / SS 316 / SS 316L or a combination of both
  • Down flow booth functions on a recirculatory airflow principle
  • At the base of the rear wall there is Prefilter to capture the airborne generated contaminants. Intake velocity at prefilters increases to offer scavenging effect
  • Continuous, clean, laminar down flow of Class 100 air supplied to work area in order to suppress
    • Any dust clouds produced during open powder processing
    • And eradicate and capture airborne particles from the operator's breathing zone
  • Triple Stage filtration
  • EU6 – Prefilter (95% down to 5 micron)
  • EU14 - HEPA Filter – Supply (99.999% down to 0.3 micron)
  • EU7 – INTERMEDIATE FILTER – Supply / Exhaust (95% down to 3 micron)
  • Balanced Motor-blower with suspension arrangement for diminishing the noise level
  • Internal covings for easy cleaning
  • SS 304 Double walled Side Panels
  • DOP Test port at upstream of HEPA filter
  • Differential Pressure Gauge : 3 Nos to monitor pressure drop across three stages of filters.
  • On / Off Switch for Motor
  • 5/15 Amp Switch Socket for external equipment
  • Fluorescent Light with Milky White Diffuser

Accessories Made Available :
  • Audio / Visual alarm for blower tripping with Fault Acknowledgement & Reset Switch
  • Clean Down Timer with Operation Hold Indicator & interlocking to put on fluorescent lights only after clean down time over
  • Sodium Vapor Lamps
  • Photohelic Gauge with Audio / Visual Alarm in lieu of Magnehelic Gauge with High / Low Indicators
  • Digital Pressure Gauge in lieu of Magnehelic Gauge
  • On Line Velocity Indicator with Audio / Visual Alarm with High / Low Indicators
  • Flame Proof Execution
  • Double skin side panels with view windows.
  • Front Anti Static PVC Curtains (for warehouse applications)
  • SS stand alone table for keeping Weighing Balance.
  • PLC Based Control System
  • Safe change Bag In / Bag Out arrangement for filters
  • SS 304 Worktable with due reinforcement


Dimensions

Model Hepa Filter Area (L x W) Work Area Dimension (L x W x H)
STRV-48-36 1220 x 915 MM 1220 x 915 x 2135 MM
STRV-48-48 1220 x 1220 MM 1220 x 1220 x 2135 MM
STRV-72-48 1830 x 1220 MM 1830 x 1220 x 2135 MM
PT-18-18-18 - 450 x 450 x 450 MM
PT-24-24-24 - 610 x 610 x 610 MM

Operating Conditions

Air cleanliness ISO Class 5 (ISO 14644-1:1999 (E))
Air Velocities 0.45 ± 0.05 mps
Air Flow Vertical - Recirculatory
Noise Level Less than 67 dB
Vibration Level Minimum
Power Supply 230V AC 1-Ø 50HZ
